Automobile & optiqueAutomotive & optics
Phares, HUD, pièces intérieures et plastiques optiques : des dépôts sous vide pensés pour des donneurs d'ordre qui lisent les tests, pas seulement les rendus.Headlamps, HUD, interior parts and optical plastics: vacuum coatings for buyers who read test results, not only renderings.
Ce que la page couvreWhat this page covers
Les équipements ZBM, ZCL et GFM sont adaptés aux lignes marocaines qui servent l'automobile export, les intégrateurs d'éclairage, les pièces décoratives et les essais process. Le langage reste technique : adhérence, réflexion, température, eau, alcalin et conformité.ZBM, ZCL and GFM systems fit Moroccan lines serving automotive export, lighting integrators, decorative parts and process trials. The language stays technical: adhesion, reflectance, temperature, water, alkaline resistance and compliance.
Paramètres utilesUseful parameters
Une table courte pour l'acheteur process. Les dossiers complets restent à demander selon la pièce et la chambre.A short table for process buyers. Full files should be requested by part and chamber configuration.
| Model | Application | Process / test | Value |
|---|---|---|---|
| ZBM1319 / ZBM1819 | Headlamp cups, PC/ABS parts | Thermal evaporation + PECVD, direct aluminium and protection film | No primer/topcoat route, adhesion grid loss <5% |
| ZCL1417 / ZCL1419 / ZCL1819 | HUD, ambient light, semi-transparent lamps | Magnetron sputtering, non-conductive translucent metal layer | Mirror front with controlled rear light transmission; high-temperature lamp tests |
| GFM1916 | Optical decorative film, reflective glass and appearance parts | Magnetron optical coating for high-reflectance or gradient optical effect | Visible reflectance above 90% where optical brightness is required |
| VFX181309 | Interior plastic, airbag cover | Vacuum fluorination surface treatment | Improves water-based paint bonding on polymer parts |
Essais et preuves par applicationTests and proof by application
Les acheteurs marocains liés à l'export automobile doivent comparer la pièce, le procédé et le test. Ces points viennent du dossier d'entreprise et servent de base pour une première revue technique.Moroccan buyers tied to automotive export need to compare the part, process and test. These points come from the company file and form a base for the first technical review.
| Family | Verification | Useful reading |
|---|---|---|
| ZBM | Adhesion tape test; cross-cut loss <5% | Checks whether direct coating can avoid primer/topcoat steps. |
| ZBM | 1% NaOH for 10 min; 40°C distilled water for 24 h | Useful for lamp parts exposed to humidity, cleaning and assembly handling. |
| ZCL | Non-conductive translucent metal layer; 170°C high-temperature box for 2 h | Relevant to ambient lighting, luminous logos and high-end lamp cups. |
| GFM | Visible reflectance above 90% | Key figure for high-reflectance optical and decorative appearance projects. |
| VFX | Vacuum fluorination before water-based paint | Improves bonding when oil-based paint is replaced by water-based coating. |
Scènes qui parlent aux acheteurs automobilesScenes automotive buyers understand
Pour les chaînes liées à l'export, l'image seule ne suffit pas. La question utile est de relier l'effet visible au contrôle process : transmission arrière pour HUD, couche métallique non conductrice pour logo lumineux, protection directe sur PC/ABS pour phare, puis essai d'adhérence avant validation.For export-linked lines, an image alone is not enough. The useful question is how the visible effect connects to process control: rear transmission for HUD, non-conductive metal layers for luminous logos, direct protection on PC/ABS headlamps, then adhesion testing before approval.
HUD / LOGO
Lecture rapide : miroir devant, lumière lisible derrière, sans perturber les signaux.Quick reading: mirror effect in front, readable light behind, without disturbing signals.
PHARES
Lecture achat : moins d'étapes peinture quand le film protecteur tient directement.Buyer reading: fewer paint steps when the protective film holds directly.
Effet visuelVisual result
Miroir, semi-transparence ou gradient selon la fonction de la pièce.Mirror, semi-transparent or gradient finishes according to part function.
Essais lisiblesReadable tests
Alcalin, eau distillée, adhérence, température et réflectance structurent la discussion.Alkaline, distilled water, adhesion, temperature and reflectance structure the discussion.
Pour le MarocFor Morocco
Approprié aux fournisseurs proches de Tanger, Kénitra et Casablanca.Relevant for suppliers near Tangier, Kenitra and Casablanca.
